Eutelsat W2A at 10.0°E

Eutelsat W2A at 10.0°E : Technical data

Eutelsat W2A at 10.0 e _ wide footprint_ first snap 001

                       satellite: Eutelsat W2A - orbit : 10.0°E - TP : 28 KU - lifetime : from 6.9.2000 - 12 years

Update : Eutelsat W2A at 10.0°E - wide footprint :spectrum analysis and measurement of quality of income

                     Eutelsat W2A at 10.0°E - wide  footprint : measurements at the center Lučenec/central Slovakia
                                                geographical location : Latitude: 48.33°  _   Longitude: 19.72°
                                            measurement results are derived from the 3.7 m diameter antenna
                                                                                  Elevation angle : 33.5°

                                  Eutelsat W2A spectral analysis                                    Eutelsat W2A footprint_wide
                                        TP B5 / wave vector H                         Europe,West Asia,ME,N Africa and E Greenland
                           Eutelsat W2A at 10.0 e _ wide footprint_ spectral analysis                  Eutelsat W2A at 10.0 e _ wide footprint
                                                                       - time of measurement : 16.1.2009 -
                                                                           - defining the status of income -

Eutelsat W2A at 10.0°E / 11 141 H Al Jazeera English : achieved in terms of quality, I measured the ideal course of
detection where is the instantaneous error BER before Vitterbi decoder stable zero,which means that the quality of MER=16.2 dB,
the gain margin of around 11 dB .

                                    Eutelsat W2A at 10.0°E - wide footprint : 10 971 V APTN News service
                         IF data                                                        Q data                                                 NIT data
Eutelsat W2A at 10.0 e _wide footprint_10 971 V feed UP8_IF dataEutelsat W2A at 10.0 e _wide footprint_10 971 V feed UP8_Q dataEutelsat W2A at 10.0 e _wide footprint_10 971 V feed UP8_NIT data

                       Eutelsat W2A at 10.0°E - wide footprint : 11 080 V DVB-S2 feed Arqiva OU Service
                       snap                                                        Q data                                                 NIT data
Eutelsat W2A at 10.0 e _wide footprint_11 080 V dvb s2 feed Arqiva encoder 9 _snapEutelsat W2A at 10.0 e _wide footprint_11 080 V dvb s2 feed Arqiva encoder 9 _Q dataEutelsat W2A at 10.0 e _wide footprint_11 080 V dvb s2 feed Arqiva encoder 9 _NIT data

                                      Eutelsat W2A at 10.0°E - wide footprint : 11 141 H Al Jazeera English
                         IF data                                                        Q data                                                 NIT data
Eutelsat W2A at 10.0 e _wide footprint_11 141 H Al Jazeera english_IF dataEutelsat W2A at 10.0 e _wide footprint_11 141 H Al Jazeera english_Q dataEutelsat W2A at 10.0 e _wide footprint_11 141 H Al Jazeera english_NIT data

                                Eutelsat W2A at 10.0°E - wide footprint : 11 149 H Syria Satellite Channel
                         IF data                                                        Q data                                                 NIT data
Eutelsat W2A at 10.0 e _wide footprint_11 149 H Syria TV_IF dataEutelsat W2A at 10.0 e _wide footprint_11 149 H Syria TV_Q dataEutelsat W2A at 10.0 e _wide footprint_11 149 H Syria TV_NIT data

                                       Eutelsat W2A at 10.0°E - wide footprint : 11 152 H DVB-S2 FTV See
                         IF data                                                        Q data                                                 NIT data
Eutelsat W2A at 10.0 e _wide footprint_11 152 H DVB S2 FTV See_IF dataEutelsat W2A at 10.0 e _wide footprint_11 152 H DVB S2 FTV See_Q dataEutelsat W2A at 10.0 e _wide footprint_11 152 H DVB S2 FTV See_NIT data

                                              Eutelsat W2A at 10.0°E - wide footprint : 11 176 H Al Forat
                         IF data                                                        Q data                                                 NIT data
Eutelsat W2A at 10.0 e _wide footprint_11 176 H Al Forat_IF dataEutelsat W2A at 10.0 e _wide footprint_11 176 H Al Forat_Q dataEutelsat W2A at 10.0 e _wide footprint_11 176 H Al Forat_NIT data

                                             Eutelsat W2A at 10.0°E - wide footprint : 11 180 H Beladi TV
                         IF data                                                        Q data                                                 NIT data
Eutelsat W2A at 10.0 e _wide footprint_11 180 H Beladi TV_IF dataEutelsat W2A at 10.0 e _wide footprint_11 180 H Beladi TV_Q dataEutelsat W2A at 10.0 e _wide footprint_11 180 H Beladi TV_NIT data

                                           Eutelsat W2A at 10.0°E - wide footprint : 12 730 V APTN Lima
                         IF data                                                        Q data                                                 NIT data
Eutelsat W2A at 10.0 e _wide footprint_12 730 V feed APTN Lima_IF dataEutelsat W2A at 10.0 e _wide footprint_12 730 V feed APTN Lima_Q dataEutelsat W2A at 10.0 e _wide footprint_12 730 V feed APTN Lima_NIT data

Eutelsat W2A at 10.0°E : TV List

 Eutelsat W2A at 10.0 e _wide footprint_PF Prodelin 3.7 m


---Frequency---


----------Provider/Channel----------

---SR--- ---FEC--- ---Footprint--- ---Antenna--- ---Video/Encryption---

10 960 -V-tp B2

 feeds APTN Beirut,Moscow... 4 167 5/6 WIDE 80-140+ cm FTA/Biss/4:2:2

10 965 -V-tp B2

 feeds APTN London,Cairo ... 4 167 5/6 WIDE 80-140+ cm FTA/Biss/4:2:2

10 970 -V-tp B2

 APTN Direct news service 4 167 5/6 WIDE 80-140+ cm DVB/FTA

10 977 -V-tp B2

feeds APTN Kabul encoder 4 ...

 4 167 5/6 WIDE 80-140+ cm FTA/Biss/4:2:2

10 982 -V-tp B2

 feeds SATLINK... 4 167 5/6 WIDE 80-140+ cm FTA/Biss/4:2:2

10 996 -V-tp B2

 feeds EBU D-170... 6 666 7/8 WIDE 80-140+ cm FTA/Biss/4:2:2

11 003 -V-tp B2

 feeds EBU RTP... 3 255 3/4 WIDE 80-140+ cm FTA/Biss/4:2:2

11 007 -V-tp B2

 feeds PTRTP-22... 3 255 3/4 WIDE 80-140+ cm FTA/Biss/4:2:2

11 017 -V-tp B2

 feeds Tandberg service... 3 125 3/4 WIDE 80-140+ cm FTA/Biss/4:2:2

11 022 -V-tp B2

 feeds ANB... 2 894 3/4 WIDE 80-140+ cm FTA/Biss/4:2:2

11 028 -V-tp B2

 feeds CYA ... 3 125 3/4 WIDE 80-140+ cm FTA/Biss/4:2:2

11 041 -V-tp B4

 feeds IHLAS n.a. ... 3 125 3/4 WIDE 80-140+ cm FTA/Biss/4:2:2

11 044 -V-tp B4

feeds IHA 1 ...

 7 200 3/4 WIDE 80-140+ cm FTA/Biss/4:2:2

11 050 -V-tp B4

 feeds Kuwait SNG ... 3 125 3/4 WIDE 80-140+ cm FTA/Biss/4:2:2

11 054 -V-tp B4

 feeds TGRT EU... 3 125 3/4 WIDE 80-140+ cm FTA/Biss/4:2:2

11 069 -V-tp B4

 feeds TGRT Ankara... 3 125 3/4 WIDE 80-140+ cm FTA/Biss/4:2:2

11 080 -V-tp B4

DVB-S2 feeds Arqiva Encoder 9 ...

 6 111 3/4 WIDE 80-140+ cm FTA/Biss/4:2:2

11 080 -H-tp B3

 feeds NDS Enc 5... 5 632 3/4 WIDE 80-140+ cm FTA/Biss/4:2:2

11 089 -V-tp B4

feeds NDS Encoder 1 ...

 5 632 3/4 WIDE 80-140+ cm FTA/Biss/4:2:2

11 098 -V-tp B4

 feeds ARQUIVA 457... 5 632 3/4 WIDE 80-140+ cm FTA/Biss/4:2:2

11 107 -V-tp B4

feeds SUI 44-4 ...

 6 666 3/4 WIDE 80-140+ cm FTA/Biss/4:2:2

11 108 -H-tp B3

DVB-S2 feeds Fi13A4 WSHT

 4 937 3/4 WIDE 80-140+ cm FTA/Biss/4:2:2

11 112 -H-tp B3

feeds Service 2 SD

 2 200 3/4 WIDE 80-140+ cm FTA/Biss/4:2:2

11 120 -H-tp B4

 feeds SNG ... 2 900
2 200		 3/4 WIDE 60-140+ cm FTA/Biss/4:2:2

11 141 -H-tp B5

 AL Jazeera English / AJE W2A 2 893 3/4 WIDE 80-140+ cm DVB FTA

11 143 -H-tp B5

 ANB 2 442 2/3 WIDE 80-140+ cm DVB FTA

11 149 -H-tp B5

 SYRIA Satellite Channel 2 893 3/4 WIDE 80-140+ cm DVB FTA

11 152 -H- tp B5

 FTV See 2 269 2/3 WIDE 80-140+ cm DVB-S2/FTA

11 157 -H- tp B5

 Al Jazeera
 		 3 978 3/4 WIDE 80-140+ cm DVB/Biss

11 163 -H-tp B5

 NourSat/Telelumiere 2 308 3/4 WIDE 60+ cm DVB FTA

11 166 -H-tp B5

 NBC 3 616 2/3 WIDE 80-140+ cm DVB-S2/8PSK
  NBC Universal Russia         Biss
  Universal Channel Russia         Biss

11 172 -H-tp B5

 Payam TV 2 532 3/4 WIDE 80-140+ cm DVB FTA

11 174 -H-tp B5

 Al Forat Network 2 531 3/4 WIDE 80-140+ cm DVB FTA

11 179 -H-tp B5

 BELADI TV 2 532 3/4 WIDE 60-140+ cm DVB FTA

11 182 -H-tp B5

 SAT-7 1 707 3/4 WIDE 60-140+ cm DVB FTA

11 182 -V-tp B6

feeds Betamobil DSNG 3 ...

 6 666 3/4 WIDE 60-140+ cm FTA/Biss/4:2:2

11 184 -V-tp B6

 feeds DSNG Prokam... 6 111 3/4 WIDE 80-140+ cm FTA/Biss/4:2:2

11 184 -H- tp B5

 Shant TV Armenia 1 698 8/9 WIDE 80-140+ cm DVB-S2/FTA

11 187 -H- tp B5

 feeds RAMATTAN SNG Gaza ... 2 000 3/4 WIDE 60-140+ cm FTA/Biss/4:2:2

11 192 -H- tp B5

 feeds SAWATEL 2 ... 3 195 3/4 WIDE 80-140+ cm FTA/Biss/4:2:2

11 278 -V- tp C3

WDS TV

 2 893 3/4 WIDE 80-140+ cm DVB/Irdeto

11 305 -V- tp C5

NBA TV

 30 000 5/6 WIDE 80-140+ cm DVB-S2/8PSK/Biss
  service 1-7 NBA 1         service line
  service 8 NBA TV         Biss

11 630 -H- tp D10

Thaqalayn  TV

 1 500 5/6 WIDE 80-140+ cm DVB-S2/MPEG-4/8PSK

11 642 -V-tp D9

feeds Creative ...

 5 209 3/4 WIDE 80-140+ cm FTA/Biss/4:2:2

12 509 -H-tp F1

feeds Cihan Video

 2 880 3/4 WIDE 80-140+ cm FTA/Biss/4:2:2

12 597 -H-tp F3

Al Sharqia test

 2 930 3/4 WIDE 80-140+ cm FTA/Biss/4:2:2

12 610 -H-tp F3

 MGM 9 259 5/6 WIDE 80-140+ cm DVB/Biss
  MGM EU         Biss
  MGM MC         Biss
  MGM ME         Biss

12 632 -V-tp F4

APGVW

8 887 2/3 WIDE 80-140+ cm DVB-S2/8PSK/Betacrypt

12 672 -V-tp D9

DVB-S2 feeds Arqiva Fapl 1 ...

 7 120 2/3 WIDE 80-140+ cm FTA/Biss/4:2:2

12 684 -V-tp F6

Disney Channel Middle East

 4 003 3/4 WIDE 80-140+ cm DVB/Biss

12 695 -V-tp F6

feeds France 2-PAR-022 ...

 5 632 3/4 WIDE 80-140+ cm FTA/Biss/4:2:2

12 704 -V-tp F6

 feeds BGVR-1 ... 6 111 3/4 WIDE 80-140+ cm FTA/Biss/4:2:2

12 713 -H-tp F5

 feeds TSA ... 6 111 3/4 WIDE 80-140+ cm FTA/Biss/4:2:2

12 729 -V-tp F6

 feeds APTN Lima ... 4 167 3/4 WIDE 80-140+ cm FTA/Biss/4:2:2

12 736 -V-tp F6

feeds UP10 Mike ....

 4 167 3/4 WIDE 80-140+ cm FTA/Biss/4:2:2

Eutelsat W1 at 10.0°E : relative quality

relative Q 01relative Q 03relative Q 05

Eutelsat W2A at 10.0°E : video presentation

      go to video section :
watch videos

Eutelsat W2A at 10.0°E footprint : Wide

                                 eutelsat W2A footprint _ wide
                         Eutelsat W2A at 10.0 e _ wide footprint

Eutelsat W2A at 10.0E : snapshots

Al Forat 05Al Jazeera 04FTV See 01
FTV See 02FTV See 03Syria TV 06
